Blue Fiber Optic Cable 3.0mm Outer Sheath ≤0.3dB Insertion Loss
  • Blue Fiber Optic Cable 3.0mm Outer Sheath ≤0.3dB Insertion Loss
  • Blue Fiber Optic Cable 3.0mm Outer Sheath ≤0.3dB Insertion Loss
Blue Fiber Optic Cable 3.0mm Outer Sheath ≤0.3dB Insertion Loss

Blue Fiber Optic Cable 3.0mm Outer Sheath ≤0.3dB Insertion Loss

Nom de marque Dawnergy
Détails de produit
Couleur des fibres:
Le bleu
Diamètre extérieur de gaine:
30,0 ± 0,2 mm
Type de connecteur:
Connecteur 3 en 1 d'un côté, de l'autre
Matériau de l'enveloppe extérieure:
PVC noir
Matériau du membre de résistance:
Fils de fibres textiles ou textiles
Longueur d'onde zéro de dispersion:
1300 à 1324
Perte par insertion (DB):
≤0,3 dB (valeur maximale)
Câble applicable:
Câble de dérivation fibre optique 3 mm
Mettre en évidence:

blue fiber optic cable 3.0mm

,

fiber optic cable low insertion loss

,

3.0mm outer sheath fiber cable

Conditions de paiement et d'expédition
Conditions de paiement
L/C, D/A, D/P, T/T
Description du produit
Blue Fiber Optic Cable with 3.0±0.2MM Outer Sheath Diameter
Technical Specifications
Attribute Value
Fiber Color Blue
Outer Sheath Diameter 3.0±0.2MM
Connector Type 3in1 Connector On One Side, Another Side NO Connector
Outer Sheath Material Black PVC
Strength member Material Aramid Yarn
Zero Dispersion Wavelength 1300~1324
Insertion Loss (dB) ≤0.3dB (Maximum Value)
Applicable Cable 3mm Fiber Drop Cable
Product Overview

High-quality fiber optic cable designed for demanding outdoor applications, featuring a durable 3.0±0.2MM outer sheath diameter and maximum insertion loss of ≤0.3dB for reliable data transmission. The cable includes a 3IN1 water-proof connector and is constructed with Aramid Yarn strength members for enhanced durability.

Key Features
  • Fiber Type: G.657A2
  • Strength member Quantity: 8pcs (2pcs water blocking)
  • Tight buffer Diameter: 0.9 ± 0.05MM
  • Zero Dispersion Wavelength: 1300~1324
  • Core Concentricity Error: ≤0.5
  • Origin: China
Applications

Ideal for outdoor telecommunications networks, internet connections, and surveillance systems. The water-proof, dust-free, and anti-corrosion properties ensure reliable performance in challenging weather conditions.

Technical Support & Services
  • Installation guidance and support
  • Troubleshooting assistance
  • Maintenance recommendations
  • User training sessions
  • Product warranty information and claims assistance
